Product introduction
The dog food making machine is an integrated piece of equipment combining powder conveying, mixing, heating, and forming. It is capable of producing extruded feed such as cat food and dog food, with support for customized molds.
Product parameters
| Model | Installed Capacity | Power Consumption | Output | Dimension |
|---|---|---|---|---|
| SY65 Pet Food Production Line | 92KW | 64KW | 120–150kg/h | 17500×2000×2500mm |
| SY70 Pet Food Production Line | 110KW | 78KW | 200–250kg/h | 19000×2000×2500mm |
| SY85 Pet Food Production Line | 240KW | 180KW | 400–500kg/h | 23000×2500×2800mm |
| SY90 Pet Food Production Line | 283KW | 190KW | 100–1200kg/h | 30000×3000×3000mm |
| SY95 Pet Food Production Line | 380KW | 266KW | 1500–1800kg/h | 34000×3000×3500mm |
| SY120 Pet Food Production Line | 430KW | 301KW | 2500–3000kg/h | 39000×3000×4000mm |
Product advantages
Precision Batching: The intelligent multi-bin batching system keeps the weighing error strictly controlled within ≤0.5%.
Uniform Coating: The twin-drum 360° rotating spraying system ensures that the seasoning powder is evenly coated.
Precise Temperature Control: The closed-loop feedback maintains the processing temperature fluctuation of the entire line within ±1°C.
Product customization
Heating Method Customization: Electric Heating / Steam Heating / Gas Heating
Control System Customization: PLC Touch Control / Button Control
Motor Brand Customization: Siemens / ABB / Schneider / Domestic Brand
Voltage Standard Customization: 220V 50Hz / 380V 50Hz / 415V 60Hz / Non-standard Voltage
Processing flow
Mixer – Screw Conveyor – Twin-Screw Extruder – Elevator – Dryer – Hoister – Flavoring Line – Cooling Conveyor
Multi-bin Batching System
Automatically and precisely weighs and mixes raw materials.
Twin-Screw Extruder System
Used for high-temperature and high-pressure extrusion forming.
Multi-layer Tunnel Dryer
Used to efficiently remove moisture from extruded pellets through hot air circulation, extending shelf life.
product applications
Pet food production line is suitable for the production of various pet foods such as dog food, cat food, pet snacks, etc. It is widely used in pet food processing plants, food companies and large production lines.
our clients
FAQ
Q: What is the MOQ for your product?
A: Our MOQ is 1 set. Any order quantities are highly appreciated.
Q: What are your terms of delivery?
A: EXW, FOB, CFR, CIF. The payment terms depend on your choice.
Q: Can I get a free sample of your dog food maker machine?
A: Yes, certainly. We would be happy to provide a sample for you. However, we kindly ask that you cover the sample and delivery costs.
Q: What is the guarantee period for your dog food machine?
A: The guarantee period for our dog food making machine is 12 months. We also offer 24-hour online service if any issues arise.
Q: How is the quality of the machine?
A: We have been in this field for many years and can supply high-quality machines for you.
Q: Do you accept OEM & ODM?
A: Yes, OEM and ODM projects are available. You are warmly welcome to customize the color, logo, company name, contacts, and any design on the pet dog food machine. We are even willing to design the color, logo, and packaging for you.
Q: Can I test your Floating Feed Pellet Machine with the raw material when visiting your factory?
A: Yes, certainly. We highly appreciate any testing of our Floating Feed Pellet Machine with the raw material.
Q: Could you provide us with a better price?
A: Of course, we can provide you with an accurate quotation based on your specific requirements and order volume.
Q: What payment methods do you accept?
A: We accept T/T, L/C, Western Union, PayPal, and MoneyGram. The payment terms are 30% deposit and 70% before delivery. We will show you photos of the products and packaging before you pay the balance.
