Automatic dry packaging extruder production manufacturer pet food machine
Product Description
Specification
Model | Installed Power | Power Consumption | Output | Size |
MT65 | 80kw | 56kw | 120-150kg/h | 22000*1200*2200mm |
MT70 | 128kw | 90kw | 200-250kg/h | 25000*1500*2200mm |
Product Details
 | Mixer Output:20-40kg/time Size:1000x800x1300mm Power:4kw 1:This mixer is used to mix the corn,wheat ,rice powder with the liquid water and some other additive.(salt,chilli powder,and some other powder). 2:About 3-5 mins for a batch. 3:mixing system is fast and stril well. 4:easy to operation. 5.this tank volumetric |
| Screw conveyor Powder:1.1kw Size : 2500x500x2300mm This screw conveyor is used to send the powder to the extruder container . |
 | double screw Extrusion machine Main Motor Power: 22kw Screw Length:1050mm Screw Diameter:65mm The use of a continuous automatic process provides greater production outputs than offered by traditional systems, with savings in energy and reduced management cost. |
 | Air conveyor Power:1.1kw Size :3000x400x3200mm This machine is use to cooling and separate the final food .There are two layers inside . |
 | baking oven Drive motor: 2.2kw. Air circulation motor: 2kw. Size: 5000 * 1200 * 2200 mm Tunnel drying, mesh belt speed is adjustable, to adjust the feed in the oven drying time, and is equipped with accurate temperature control device, easy to adjust. |
 | cooling machine Power:0.77KW Dimension:6000 x 800 x 1000mm Out of the dressing machine, surface must have a lot of oil, and the oven keypad for completely faded, 8 m mesh belt to reduce temperature of the material and make the oil content and have attractant is absorbed adequately and can reach the level of direct packaging. |
Company Profile
Packing&Delivery
Our Services
Feedback
Q6: Do you make customized machine? A6: Yes, we provide machine custom service according to customer's requirements. We also provide turnkey solution if customer require.
