The investment for this line is only one tenth of that large size equipment,especially suitable to small-size or self-owned enterprises,the corrugated instant noodle produced by this line tenacious,smooth and transparent,it is very easy to be saturated by water.
Cup and bag package Instant noodle making machine production line
Full automatic instant Ramen Noodles machine line Extruding Instant Noodle rice fast food equipment.
Full automatic instant Ramen Noodles machine line Extruding Instant Noodle rice fast food equipment.with perfect technology,compact structure,original design and stable performance,is developed on the base of like produces and requirements in the world market,it realizes high automation ,convenient operation,low energy and small floor space ,that assures all working procedures from feeding flour to finished products can be accomplished once.
Product parameters
|
Model
|
SY5-250(Wet noodles)
|
SY5-260
|
SY5-260(Integrated machine)
|
SY5-300
|
|
Roller Groups
|
5
|
5
|
5
|
5
|
|
Width of Roller
|
96-250mm
|
138-260mm
|
138-260mm
|
138-300mm
|
|
Output
|
150-180kg/h
|
170-200kg/h
|
235kg/h
|
220kg/h
|
|
Power
|
3kw
|
3kw
|
3kw
|
3kw
|
|
Weight
|
400kg
|
500kg
|
660kg
|
600kg
|
|
Size
|
1570*650*1370mm
|
1590*670*1370mm
|
2400*680*1450mm
|
1640*750*1370mm
|
Main Machine Detail
Mixer
Capacity:80-100kg/h
Power:3kw Size:1170*850*950mm Function:mixing raw material with water,like the wheat flour,egg,salt and so on.
Capacity:80-100kg/h
Power:3kw Size:1170*850*950mm Function:mixing raw material with water,like the wheat flour,egg,salt and so on.
Roller pressing machine
Power:4kw
Output:70-100kg/h
Size：2300*700*1450mm
Function:
To make noodle-shaping
Size：2300*700*1450mm
Function:
To make noodle-shaping
Fryer machine.
apacity: 80-100kg/h Power: 64kw Size: 6000*870*1200mm Function:This machine for frying noodle and also finalize the design. The
shape and size of the noodles can be changed by changing the noodle box.
shape and size of the noodles can be changed by changing the noodle box.
Power:0.77kw
Output:70-100kg/h
Size: 6000*700*800mm
Function:
Have a cool the noodle
Blow the noodles with cold air to cool. After that, check the weight, shape, color, dryness, fried state, cooling temperature,etc.
Compound Roller Machine
Output: 80-100kg/h Power: 4kw Size: 3000 * 600 * 1500mm Function: This machine can be made into noodle shapes, and noodles of
different sizes can be made according to the noodle forming machine.
Output: 80-100kg/h Power: 4kw Size: 3000 * 600 * 1500mm Function: This machine can be made into noodle shapes, and noodles of
different sizes can be made according to the noodle forming machine.
Boiling machine
Capacity: 80-100kg/h Power:126kw()electricity type) Power: 5kw(steam type,but you need match boiler in addition)
Size:14000*500*1260mm Function: This machine for cooking noodle to finalize the design.
Capacity: 80-100kg/h Power:126kw()electricity type) Power: 5kw(steam type,but you need match boiler in addition)
Size:14000*500*1260mm Function: This machine for cooking noodle to finalize the design.
Fryer machine
Capacity: 80-100kg/h Power: 64kw Size: 6000*870*1200mm Function:This machine for frying noodle and also finalize the design. The
shape and size of the noodles can be changed by changing the noodle box.
Capacity: 80-100kg/h Power: 64kw Size: 6000*870*1200mm Function:This machine for frying noodle and also finalize the design. The
shape and size of the noodles can be changed by changing the noodle box.
Parts:If you buy our machine, we will prepare some free accessories and toolboxes.
Product Show
Instant Noodles Instant noodles are made from wheat flour, starch, water, salt or kan sui (an alkaline salt mixtureof sodium carbonate, potassium carbonate, and sodium phosphate), and other ingredients that improve the texture and flavor of noodles.
Packing & Delivery
♥Wooden or metal case according to specific size of each equipment, we twine thick plastic coating for each machine.
♥Tight the equipment in the truck without space to ensure no rubbing during the transportation.
♥Tight the equipment in the truck without space to ensure no rubbing during the transportation.
Our Company
